SVX-6 BROCHURE
FUTURE OF EXPEDITION
INTRODUCING THE SVX-6
Engineered to combine uncompromising off-road capability with premium comfort and class-leading efficiency, the SVX-6 delivers a level of design, strength and refinement rarely seen in a compact touring platform.
From its true monocoque composite body and advanced one-piece chassis to its large, spacious & luxurious interior. Combined With a seperate internal ensuite, 250 litre fridge/freezer, true internal kitchen & full off-grid systems, every element has been developed to give owners more without the bulk, weight or compromise of conventional alternatives.
The result is an expedition vehicle that is lighter, stronger, smarter and purpose-built for remote Australia.
FLOORPLAN
DIMENSIONS
SPECIFICATIONS
DIMENSIONS
WEIGHTS
BODY LENGTH:
OVERALL LENGTH:
BODY WIDTH:
MAX HEIGHT:
LOW HEIGHT:
MAX TYRE SIZE:
GROUND CLEARANCE:
5,400MM / 17.7FT
6,760MM / 22.1FT
2,100MM
2,975MM
2,800MM
37 INCHES
700MM
TARE WEIGHT:
BALL WEIGHT:
ATM:
PAYLOAD:
2,250KG
120KG
3,500KG
1,250KG
FLUID CAPACITY
320 LITRES
50 LITRES
DRINKING WATER:
GREY WATER:
SVX-6 PRICE: $218,990
* Weights, Dimensions & specifications may fluctuate depending on options and build selections.
STANDARD INCLUSIONS
CHASSIS
-
Tekton Certified Engineered Chassis (FEA Tested)
-
150 x 50 x 3mm Main Chassis Rails
-
450 Grade Steel
-
Light Weight
-
Laser/CNC Cut Sections
-
Fully Welded & Sealed Chassis
-
2K (Two Pac) Epoxy Performance Coating Black
DO35: 3500kg Off-Road Hitch
-
Ark XO 750 Off-Road Twin Jockey Wheel
-
Corner Stabiliser Jacks
-
Two Rear Recovery Points
-
Rear Protection Bar
-
Dual Rear Mounted Spare Tyre
SUSPENSION
-
Teko Independent Airbag Suspension System
-
Auto Levelling
-
Four Shock Absorbers
-
Air Compressor (Internal)
-
15 Litre Air Tank (Internal)
-
Air Outlet With Hose To Inflate Tyres
TYRES & BRAKES
-
12" Electric/Hydraulic Disc Brakes
-
6x 17" ROH Vapour Rims
-
6x All Terrains 265/70x17
WATER CAPACITY
-
2x 110 Litre (220L) Baffled External Drinking Water Tank Bash Plate Protection
-
2x 50 Litre (100L) Baffled External Drinking Water Tank Bash Plate Protection
-
50 Litre Grey Water Tank Baffled External With Bash Plate
BODY CONSTRUCTION
-
30mm Engineered Structural Composite Panels
-
Tekton EV Monocoque/Unibody Technology
-
Extremely Energy & Thermal Efficient
-
Epoxy Urethane Protective Paint Coating (Complete Body) (Any Colour)
EXTERNAL FEATURES
-
Front Large Lockable Storage Box 2x Side Opening Doors (Urethane Protective Coating)
-
Custom Utility Rack On Front Box (Urethane Protective Coating)
-
Lockable Tunnel Storage Compartment (Urethane Protective Coating)
-
2x Large Lockable Storage Hatches
-
External Kitchen (Sink & 2 Burner Portable Induction Cooktop)
-
External Pantry
-
3x Body Mounted LED Camping Light (White & Amber)
-
External Shower (Hot/Cold)
-
5.0m Box Awning LHS
-
External 240V / 12V / USB Outlets
-
Entry Step
-
External Grab Handle With LED
-
Carbon Fibre Housed Dust Suppression System (DSS)
-
LED Rock Lights Under Mounted
ELECTRICAL
-
800 AMP Lithium Battery Bank
-
1,425 Watts Twin Cell Monocrystalline Solar Panels
-
3,000 Watt Victron Pure Sine Wave Inverter With Automatic AC Transfer
-
120 AMP Victron AC Charger
-
50 AMP Victron DC-DC Charger
-
Victron 80 AMP MPPT Solar Charger
-
Integrated Touch Screen Power Management System & Digital Monitoring / Switches
-
External Solar Input
-
Trail Safe Break Away Control System
-
7 Pin Plug Flat
-
Anderson Plug
KITCHEN & DINING
-
2x European Side Windows With Reflective Blinds & Insect Mesh
-
Leatherette Lounge with Bespoke Stitching
-
Cafe Dinette Or L-Shape Lounge (Provision For Bed)
-
Internal T.V Provision
-
190 Litre Compressor Fridge/Freezer
-
12v Water Pump
-
Internal Tank Selection
-
Mains Water Pressure Regulator
-
Kitchen LED Lighting (Dimmable)
-
Soft Close Cupboards & Draws
-
240V Outlets
-
Diesel Hot Water Service & Heating System
-
2x Three Speed Adjustable Sirocco Fans
-
Leather Pouch
BEDROOM
-
Queen Size HydroFlex Mattress
-
2x LED Bed Reading Lamps With Night Light
-
Bed Area LED Lighting (Dimmable)
-
2x Dual USB / 12V Outlets (Bed Area)
-
Leatherette Bed Head With Bespoke Stitching
-
Large Clothing Cupboards & Draws
-
2x European Side Windows With Reflective Blinds & Insect Mesh
-
1x Stargazing European Window With Reflective Blinds & Insect Mesh
ENSUITE
-
Internal Separate Shower & Toilet Ensuite
-
Basin & Vanity
-
Draws & Cupboards
-
OGO Composting Toilet
-
Ensuite LED Lighting (Dimmable)
-
Large Mirror
-
Double 240V GPO Power Point
-
1x European Side Windows With Reflective Blinds & Insect Mesh
OPTIONAL EQUIPMENT
CHASSIS & SUSPENSION
-
Stud Pattern Change
-
Rims/Tyre Change
-
20K IBS Rear Recovery Winch
ELECTRICAL
-
1,660 Watt Twin Cell Monocrystalline Solar Panel Upgrade
-
1,200 AMP Lithium Battery Upgrade
-
1,600 AMP Lithium Battery Upgrade
-
Rear View Camera
INTERIOR & KITCHEN
-
Air-Conditioning System
-
2.5kg Washing machine
-
Microwave Oven
-
Diesel Convection Oven
-
Diesel 2 Burner Cooktop (Internal)
EXTERIOR
-
Additional Body Mounted LED Camping Light RHS (White & Amber)
-
Additional Body Mounted LED Camping Light Rear (White & Amber)
-
Additional 5.0M Box Awning RHS (Driver Side)
-
Bbq / Fridge / Generator Slide (Tunnel Box Or Front Box)
-
MaxTrax
Tekton Expedition Vehicles optional equipment list may be limited to specific models only, please contact our sales team when deciding what options to purchase. Advertised prices and weights on all advertised details are current at time of publication but can change anytime forthwith. Photos are indicative only. Tekton Expedition Vehicles retains all the rights to all designs, dimensions and specifications. Tekton Expedition Vehicles acknowledges that advertised weights and prices may vary due to the nature of manufacturing accessories and third party suppliers. Fixtures, fittings and finishes are subject to availability and supplier discretion. This brochure is only a quide and does not constitute an offer or contract.
